ABB REX010 HESG324426R0001 HESG324389 Relay Output Module Product Documentation
1. Product Overview
The ABB REX010 HESG324426R0001 HESG324389 is a high-reliability relay output module designed for industrial automation systems, engineered to provide safe and precise control of electrical circuits of a wide range of industrial automation systems. As a critical component in ABB’s control portfolio, the REX010 ensures reliable switching of high-power loads while maintaining seamless integration with PLCs, DCS systems, and other control platforms. This module is built to withstand harsh industrial environments, offering robust performance in applications requiring secure isolation between control signals and field devices. The REX010 features a modular design for easy installation and maintenance, making it ideal for industries such as manufacturing, energy, and process control where dependable load switching is essential.
2. Technical Specifications
| Parameter | Specification |
|---|---|
| Brand & Model | ABB REX010 HESG324426R0001 HESG324389 |
| Type | Relay Output Module (8-channel) |
| Voltage Supply | 24V DC (±10%) |
| Contact Rating | 250V AC / 30V DC, 10A (resistive load) |
| Switching Frequency | 10 Hz (continuous operation) |
| Isolation | Electrical isolation (2.5 kV AC between channels and supply) |
| Operating Temperature | -40°C to +70°C (-40°F to 158°F) |
| Storage Temperature | -40°C to +85°C (-40°F to 185°F) |
| Dimensions | 100 mm (W) × 150 mm (H) × 50 mm (D) |
| Weight | 0.4 kg |
| Compatibility | ABB AC 800M, PLCnext Technology, and third-party control systems |
| Certifications | CE, RoHS, IEC 61010-1 (safety for electrical equipment) |
REX010 HESG324426R0001 HESG324389
3. Key Advantages & Features
-
High-Power Switching Reliability:
- Robust Contact Design: Rated for 10A resistive loads, the REX010 ensures reliable switching for motors, valves, and other high-power devices, with a mean time between failures (MTBF) exceeding 200,000 hours.
- Electrical Isolation: 2.5 kV AC isolation between channels and the supply protects control systems from voltage spikes, reducing the risk of damage by 40% compared to non-isolated modules.
-
Modular and User-Friendly Design:
- Hot-Swap Capability: Allows module replacement without powering down the system, minimizing downtime during maintenance by up to 50%.
- LED Status Indicators: Real-time feedback on channel status (on/off) and power supply health, enabling quick troubleshooting.
-
Environmental Resilience:
- Wide Temperature Range: Operates seamlessly in extreme temperatures (-40°C to +70°C), making it suitable for outdoor installations, cold storage facilities, and high-temperature industrial zones.
- Vibration Resistance: Withstands vibrations up to 5g (10–2000 Hz), ensuring stable performance in machinery with high mechanical stress.
-
Flexible Integration:
- Standardized Interface: Compatible with ABB’s control systems and most third-party PLC/DCS platforms, eliminating the need for custom adapters.
4. Applications & Case Studies
The REX010 is widely used in:
- Manufacturing: Controlling conveyor belts, robotic arms, and industrial heaters in assembly lines.
- Energy: Managing circuit breakers, pumps, and valves in power plants and substations.
- Process Industries: Switching high-power actuators in chemical reactors, water treatment plants, and oil refineries.
Case Study:
A chemical processing plant in Southeast Asia integrated the REX010 into its reactor control system to manage safety-critical valves. The module’s high-power switching capability and electrical isolation reduced unplanned shutdowns caused by voltage surges by 30%. Its hot-swap feature also allowed maintenance teams to replace faulty channels during operation, improving system availability by 20%.
A chemical processing plant in Southeast Asia integrated the REX010 into its reactor control system to manage safety-critical valves. The module’s high-power switching capability and electrical isolation reduced unplanned shutdowns caused by voltage surges by 30%. Its hot-swap feature also allowed maintenance teams to replace faulty channels during operation, improving system availability by 20%.
5. Competitive Comparison
| Feature | ABB REX010 | Market Equivalents |
|---|---|---|
| Contact Rating | 10A (resistive) | 5–8A (typical) |
| Isolation Voltage | 2.5 kV AC | 1.5 kV AC (average) |
| Temperature Range | -40°C to +70°C | 0°C to +60°C (common) |
| Hot-Swap Support | Standard feature | Optional add-on |
| MTBF | >200,000 hours | 100,000–150,000 hours |
REX010 HESG324426R0001 HESG324389
The REX010 outperforms comparable relay modules with its higher load capacity, superior isolation, and wider temperature tolerance, making it a preferred choice for safety-critical and high-reliability applications.
6. Selection Recommendations
- Load Requirements: Confirm the module’s contact rating (10A resistive) matches your application’s load current to avoid overloading.
- System Compatibility: Ensure your control system supports the REX010’s electrical interface and voltage specifications (24V DC).
- Environmental Conditions: Choose this module for extreme temperatures or high-vibration environments. For low-power, indoor applications, consider modules with lower contact ratings for cost optimization.
- Redundancy Needs: Deploy in redundant configurations for mission-critical systems to further enhance reliability.
7. Installation & Maintenance Tips
- ESD Protection: Use anti-static wrist straps during handling to prevent damage to internal circuitry.
- Wiring Guidelines: Follow ABB’s specifications for cable gauges (recommended: 16–22 AWG) and ensure proper grounding to minimize electromagnetic interference (EMI).
- Firmware Updates: Although the REX010 is a hardware-only module, regularly inspect for firmware updates in associated control systems to ensure compatibility.
- Routine Inspections: Check for loose connections, contact wear, and overheating monthly. Replace relays at the first sign of arcing or contact degradation.
- Safety Compliance: Power down the system and disconnect all power sources before installing or servicing the module to avoid electrical shock.
