Description
Product Overview
The ABB UFC718AE01 HIEE300936R0101 is a high-performance uninterruptible power supply (UPS) module designed for industrial automation systems, providing reliable and continuous power to critical control components. As part of ABB’s Industrial UPS Solutions portfolio, this module is engineered to protect against power disruptions, voltage sags, and transient surges, ensuring uninterrupted operation of PLCs, HMIs, and communication networks in demanding industrial environments. The UFC718AE01 HIEE300936R0101 combines advanced battery management, real-time diagnostics, and compact design to deliver seamless power backup for applications where downtime is costly, such as manufacturing, oil & gas, and power generation.
Featuring a 1 kVA power rating and flexible input/output configurations, the module supports both single-phase and three-phase power systems, adapting to diverse industrial setups. Its intelligent battery charger extends battery lifespan through controlled charging cycles, while the built-in static switch ensures rapid transfer to battery power (≤4 ms) during outages, minimizing data loss or process interruptions. The UFC718AE01 HIEE300936R0101 integrates seamlessly with ABB’s 800xA control system via Modbus RTU, enabling remote monitoring of battery status, load levels, and fault conditions, thus enhancing operational visibility and maintenance efficiency.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | UFC718AE01 HIEE300936R0101 |
| Manufacturer | ABB |
| Product Type | Industrial UPS Module |
| Power Rating | 1 kVA |
| Input Voltage Range | 100–240 V AC (single-phase) |
| Output Voltage | 24 V DC ±1% |
| Battery Type | Sealed lead-acid (SLA), 12 V × 2 (configurable) |
| Backup Time | 5–30 minutes (depending on load and battery capacity) |
| Transfer Time | ≤4 ms (AC to DC) |
| Operating Temperature | 0°C to +40°C (with derating above +25°C) |
| Dimensions (W×H×D) | 100 mm × 200 mm × 150 mm |
| Mounting Method | DIN rail or wall mounting |
| Certification | CE, UL, IEC 62040-1-1, RoHS |
| Communication | Modbus RTU (RS-485) |
UFC718AE01 HIEE300936R0101
Main Features and Advantages
Reliable Power Protection: The UFC718AE01 HIEE300936R0101 ensures continuous power supply during grid disturbances, with a fast transfer time that prevents data corruption in control systems. Its double-conversion topology provides pure sine wave output, filtering out electrical noise and harmonics, making it suitable for sensitive equipment like servo drives or analytical instruments in pharmaceutical plants.
Intelligent Battery Management: The module’s adaptive charging algorithm optimizes battery performance, reducing maintenance requirements and extending service life by up to 30%. Built-in battery diagnostics monitor voltage, temperature, and state of charge (SoC), triggering alarms via Modbus when replacement is needed. For example, in a 24/7 production line, early battery fault detection prevents unexpected downtime during critical operations.
Compact and Flexible Design: With a footprint of just 100 mm width, the UFC718AE01 HIEE300936R0101 fits into space-constrained control panels, ideal for retrofitting older systems. It supports parallel operation for higher redundancy (e.g., dual UPS modules in a server room), while the hot-swappable battery compartment allows safe replacement without powering down the system, minimizing maintenance risks in live industrial environments.
Remote Monitoring and Control: Through Modbus RTU, the module integrates with ABB’s Ability™ digital platform, enabling real-time tracking of key parameters like input voltage, load percentage, and battery health. This feature is critical in distributed facilities, where centralized monitoring of multiple UPS units reduces 巡检 costs and ensures compliance with ISO 44001 standards for integrated management systems.
UFC718AE01 HIEE300936R0101
Application Field
The ABB UFC718AE01 HIEE300936R0101 is essential in industries where uninterrupted power is non-negotiable:
- Manufacturing: Protects PLCs and robotics in automotive assembly lines, ensuring production continuity during transient power issues. For instance, in a semiconductor fab, the UPS maintains clean power to lithography machines, preventing costly wafer defects from power interruptions.
- Oil and Gas: Used in offshore platforms and refineries to power emergency shutdown systems (ESD) and safety instrumented systems (SIS), complying with IEC 61508 standards for functional safety. The module’s rugged design withstands vibration and temperature fluctuations in these harsh environments.
- Power Generation: Supports SCADA systems in substations, ensuring remote monitoring of grid status during outages. In renewable energy plants, it keeps wind turbine control systems operational during short-term grid losses, enabling smooth transition to island mode.
- Healthcare and Pharmaceuticals: Powers critical equipment like sterilizers and bioreactors, where even brief power interruptions can compromise product quality or patient safety. The UPS’s low noise and high efficiency align with cleanroom requirements in pharmaceutical manufacturing.
Related Products
- ABB UFC721AE01: A 3 kVA variant for higher-power applications, such as large control rooms or multiple PLC systems.
- ABB UFC718BE01: A redundant UPS module with dual input sources, designed for mission-critical systems in data centers or aviation.
- ABB BAT718: Replacement battery pack for the UFC718 series, ensuring quick maintenance and consistent backup performance.
- ABB PM866AK01: A control module compatible with the UFC718AE01, enabling integrated power management within ABB’s AC 800M system.
- ABB TP830: A baseplate for DIN rail mounting, enhancing mechanical stability in high-vibration environments.
Installation and Maintenance
Pre-installation preparation: Mount the UFC718AE01 HIEE300936R0101 on a grounded DIN rail or wall bracket, ensuring adequate ventilation (minimum 50 mm clearance on all sides). Connect the input/output cables using stranded copper wires (max. 4 mm²), following the polarity markings to avoid damage. Configure the UPS settings (e.g., battery type, alarm thresholds) via the front-panel LCD or Modbus interface, and perform a load test to validate backup functionality.
Maintenance recommendations: Inspect the battery compartment quarterly for signs of corrosion or swelling, and clean the module’s vents with compressed air to prevent dust accumulation. Test the battery’s SoC annually using ABB’s UPS Monitor software, replacing batteries if capacity drops below 80%. Update the module’s firmware every two years to access new features like enhanced harmonic filtering or communication protocols. In case of a fault, use the front-panel diagnostics or Modbus alerts to identify issues, and replace faulty components with ABB-certified spares to maintain system reliability.
Product Guarantee
ABB stands behind the UFC718AE01 HIEE300936R0101 with a 5-year warranty, covering defects in materials and workmanship. ABB’s global service network provides 24/7 technical support, including remote diagnostics and on-site maintenance for critical failures. The module’s compliance with international safety standards and ABB’s rigorous testing (e.g., 10,000-cycle transfer tests) ensures long-term reliability, while the company’s lifecycle management programs offer upgrade paths to newer UPS technologies as needed. By combining robust performance with advanced digital features, the UFC718AE01 HIEE300936R0101 delivers peace of mind for industrial operators relying on uninterrupted power to safeguard productivity and safety.
