IC697CPX928-FE Product Specification
The IC697CPX928-FE is a high-performance communication processor module designed for Allen-Bradley’s CompactLogix automation platform. Engineered to enable seamless integration and real-time data exchange, the IC697CPX928-FE supports multiple industrial protocols and enhances system connectivity in diverse applications.
1. Product Overview
The IC697CPX928-FE serves as a critical bridge between field devices, controllers, and enterprise networks. Its core functions include protocol conversion, data routing, and remote monitoring. Key advantages of the IC697CPX928-FE include its dual-port Ethernet capability, support for EtherNet/IP and Modbus TCP, and rugged design for harsh environments. This module is ideal for applications requiring reliable communication in manufacturing, energy, and infrastructure sectors.
2. Technical Parameters
| Parameter | Specification |
|---|---|
| Protocol Support | EtherNet/IP, Modbus TCP, DF1 |
| Communication Ports | 2 x 10/100 Mbps Ethernet |
| Voltage Range | 12-24 VDC |
| Current Consumption | 500 mA @ 24 VDC |
| Compatibility | Allen-Bradley CompactLogix (e.g., 1769-L32E) |
| Redundancy | Supports dual module configuration |
| Data Rate | Up to 100 Mbps |
IC697CPX928-FE
3. Advantages and Features
- Multi-Protocol Flexibility: The IC697CPX928-FE handles mixed protocol environments, reducing the need for additional gateways.
- High-Speed Performance: Achieves sub-millisecond data transfer, critical for real-time control systems.
- Redundancy Support: Dual-port architecture ensures uninterrupted operation in case of network failure.
- Remote Access: Enables secure remote troubleshooting and firmware updates.
Case Study: A chemical plant implemented the IC697CPX928-FE to integrate legacy Modbus devices with EtherNet/IP controllers, cutting downtime by 30%.
4. Application Areas and Use Cases
The IC697CPX928-FE is widely used in:
- Manufacturing: Machine-to-machine communication in automotive assembly lines.
- Energy: Monitoring distributed generators in smart grids.
- Water/Wastewater: Centralized control of pump stations across a city network.
Example: In a logistics warehouse, the IC697CPX928-FE coordinated AGV (Automated Guided Vehicle) systems via EtherNet/IP, improving throughput by 25%.
5. Competitor Comparison
Compared to similar communication modules, the IC697CPX928-FE offers faster protocol switching and a broader range of supported standards. Its built-in security features (e.g., IP filtering) also enhance network protection without requiring external firewalls.
IC697CPX928-FE
6. Selection Recommendations
- Protocol Requirements: Choose the IC697CPX928-FE if your system needs EtherNet/IP and Modbus TCP integration.
- Redundancy Needs: Opt for dual-module setup (e.g., two IC697CPX928-FE modules) for mission-critical applications.
- Scalability: Ensure compatibility with your CompactLogix chassis (e.g., 1769-AENTR for expansion).
7. Precautions
-
Network Configuration: Avoid IP address conflicts by using Allen-Bradley’s RSLogix 5000 software for setup.
-
Power Supply: Use a filtered power source to prevent voltage spikes.
-
Firmware Updates: Regularly update firmware via Rockwell Automation’s Connected Components Workbench.
