GE Fanuc IC697PWR710F High-Efficiency Power Supply Module
The IC697PWR710F is a high-reliability power supply module from GE Fanuc’s Series 90-70 PLC platform, designed to deliver stable 24V DC power to industrial automation systems. With 10A continuous output and 90% efficiency, this module ensures seamless operation of PLCs, I/O modules, and field devices in manufacturing, energy, and water treatment applications. Its wide input voltage range (85–264V AC) and -20°C to +60°C temperature tolerance make it suitable for global industrial environments.
1. Product Overview
The IC697PWR710F serves as the power backbone for GE’s Series 90-70 systems, providing overload protection, short-circuit recovery, and EMI filtering to safeguard against voltage spikes and electrical noise. Its compact design (100mm x 150mm x 80mm) and DIN-rail mounting simplify installation in confined spaces, while hot-swap capability minimizes downtime during maintenance.
2. Technical Specifications
| Parameter | Specification |
|---|---|
| Input Voltage | 85–264V AC (47–63Hz) |
| Output Voltage | 24V DC ±5% (adjustable via potentiometer) |
| Output Current | 10A continuous, 15A peak (30 seconds) |
| Efficiency | ≥90% at full load |
| Power Factor | ≥0.95 (active PFC) |
| Protection | Overload, short-circuit, over-temperature |
| Operating Temperature | -20°C to +60°C (ambient) |
| Compatibility | GE Fanuc Series 90-70 PLCs |
IC697PWR710F
3. Key Advantages
- Energy Savings: 90% efficiency cuts energy costs by $3,000/year in a typical 10-module system (case study: U.S. automotive plant).
- Fault Tolerance: Auto-recovery from short circuits (50ms reset time), reducing downtime by 70% compared to non-protected supplies.
- Global 适用性: Wide input voltage range eliminates the need for local transformers in international deployments.
4. Applications & Use Cases
- Manufacturing: Powers robotic welding systems in automotive plants, ensuring 99.99% uptime (e.g., German factory reduced weld defects by 35%).
- Energy: Supports gas turbine control systems in power plants, optimizing fuel efficiency by 8% (U.S. plant saved $500K/year).
- Water Treatment: Drives pumps and valves in wastewater facilities, achieving ±0.5% pressure stability (European plant cut chemical usage by 18%).
Case Study: A Middle Eastern refinery deployed IC697PWR710F in dual redundancy, eliminating 8 power-related failures over 3 years, saving $500,000 in downtime costs.
5. Competitor Comparison
- Efficiency: 90% vs. 85% in comparable modules, delivering higher energy savings.
- Temperature Range: Operates at -20°C to +60°C vs. -10°C to +50°C in legacy models.
- Power Factor: 0.95 vs. 0.85, reducing reactive power consumption.
IC697PWR710F
6. Selection Recommendations
- Current Needs: Choose IC697PWR710F for 8–10A loads; downsize to IC697PWR705F (5A) for small systems.
- Redundancy: Pair with GE’s IC697PWR710F-EC for N+1 redundancy in critical processes.
- Environment: Opt for IC697PWR710F-H (IP65-rated) for outdoor/washdown applications.
7. Installation & Maintenance Notes
- Wiring: Use 10AWG cables for input/output; torque terminals to 0.8 N·m to prevent loose connections.
- Cooling: Maintain 10mm airflow clearance; add a fan for ambient temperatures >50°C.
- Testing: Annual load tests (80% capacity for 2 hours) ensure long-term reliability.
