  • High-Speed Connectivity: 100 Mbps throughput (2x faster than legacy 485-based modules) for real-time control.
  • Reliability: MTBF > 300,000 hours (third-party tested) with dual-port redundancy (ring topology support).
  • Flexible Networking: Configurable as adapter, scanner, or device; supports CIP Motion for motion control systems.
  • Security: Built-in firewall and encrypted data transfer (AES-128) for industrial IoT (IIoT) applications.
  • Ease of Use: Pre-configured templates in GE’s Proficy Machine Edition (PME) reduce commissioning time by 50%.
Get a Quote
In Stock
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide. Brand:

Description

1. Product Description

The GE IS215VCMIH2C is a high-speed EtherNet/IP communication module designed for GE’s PACSystems RX3i programmable automation controller (PAC) platform. As part of the IS215 series, the IS215VCMIH2C enables seamless integration with industrial networks, supporting real-time data exchange between PLCs, HMIs, and smart devices. With dual-port Ethernet (10/100 Mbps) and advanced security features (SNMPv3, IEEE 802.1X), this module ensures reliable connectivity in critical applications. Its plug-and-play design, support for CIP (Common Industrial Protocol), and compatibility with GE’s Proficy software make it ideal for scalable automation systems. The module’s rugged construction (IP20-rated, IEC 61000-6-2/6-4 compliance) ensures operation in harsh environments, while redundant power (24 VDC) and fault-tolerant networking reduce downtime.

2. Product Specifications

Parameter Details
Voltage Power Supply: 24 VDC (±10%)
Communication Protocol: EtherNet/IP (CIP); Ports: 2 × RJ45 (auto-negotiation)
Data Rate 10/100 Mbps (full-duplex)
Compatibility GE PACSystems RX3i (e.g., IS215ACSSI1A, IS215UCVAI1B); CIP Sync, CIP Safety
Security SNMPv3, IEEE 802.1X, IP filtering
Operating Temperature -40°C to +70°C (extended industrial range)
Network Nodes Up to 254 devices per network
Dimensions 127 mm (H) × 102 mm (W) × 38 mm (D)
Certifications CE, UL 508, IEC 61131-2 (Class B)
IS215VCMIH2C

IS215VCMIH2C

3. Advantages and Features

  • High-Speed Connectivity: 100 Mbps throughput (2x faster than legacy 485-based modules) for real-time control.
  • Reliability: MTBF > 300,000 hours (third-party tested) with dual-port redundancy (ring topology support).
  • Flexible Networking: Configurable as adapter, scanner, or device; supports CIP Motion for motion control systems.
  • Security: Built-in firewall and encrypted data transfer (AES-128) for industrial IoT (IIoT) applications.
  • Ease of Use: Pre-configured templates in GE’s Proficy Machine Edition (PME) reduce commissioning time by 50%.

4. Application Areas and Use Cases

Industries: Manufacturing (assembly lines), energy (smart grids), automotive (robotics), water/wastewater (SCADA).
Use Case: A global automotive plant deployed 20+ IS215VCMIH2C modules to connect 500+ robots and sensors on an EtherNet/IP network. The module’s CIP Motion support and dual-port redundancy eliminated network bottlenecks, reducing cycle time by 15% and improving uptime to 99.98%.

5. Competitive Comparison

Compared to similar EtherNet/IP modules:
  • Redundancy: Dual-port ring topology (vs. single-port in many alternatives).
  • Security: Built-in AES encryption (vs. optional add-ons in competitive models).
  • Protocol Support: Native CIP Safety (SIL 3 capable) and CIP Sync (precision time synchronization).
  • Temperature Range: Operates at +70°C (vs. standard 55°C in most competitor modules).
    IS215VCMIH2C

    IS215VCMIH2C

6. Selection Recommendations

  • System Type: Ideal for GE PACSystems RX3i; verify backplane compatibility (e.g., IS215BPV01B).
  • Network Requirements: Choose for high-bandwidth applications (e.g., machine vision, motion control).
  • Environment: Suitable for extreme temperatures (-40°C to +70°C) or EMI-prone areas (industrial floors).
  • Scalability: Pair with GE’s IS215UCVAI1B universal controller for distributed network expansion.

7. Precautions

  • Installation: Follow ESD protocols; use shielded Cat5e/6 cables (max length: 100 m for EtherNet/IP).
  • Network Configuration: Avoid IP address conflicts; use GE’s Proficy Network Configuration Tool for topology design.
  • Firmware Updates: Regularly update firmware (via PME) to patch security vulnerabilities.
  • Power Stability: Ensure 24 VDC supply with transient protection (surge: 400 V, 10 ms).
  • Safety Compliance: For SIL 3 systems, use with GE’s CIP Safety-certified devices (e.g., IS215VCMIH2C + IS215SCMIH1A).
