  1. Dual-Port Redundancy:
    • Eliminates single points of failure with A/B port redundancy, ensuring continuous communication even if one port fails.
    • Case: In a gas power plant, IS220PPROS1B reduced downtime by 95% during port maintenance compared to non-redundant modules.
  2. High-Speed Data Transfer:
    • Supports 12 Mbps bandwidth, 30% faster than standard PROFIBUS modules, ideal for real-time control of fast-acting valves in turbines.
  3. Hot Swap Capability:
    • Modules can be replaced without powering down the system, minimizing maintenance time by up to 80%.
  4. Wide Environmental Tolerance:
    • Operates in extreme temperatures (-40°C to 70°C) and high vibration environments, making it suitable for offshore and harsh industrial settings.
Get a Quote
In Stock
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide. Brand:

Description

1. Product Description

IS220PPROS1B is a PROFIBUS DP/V1 Communication Processor Module designed by GE Fanuc for its Mark VIe Gas Turbine Control System. It serves as a critical interface between the Mark VIe controller and PROFIBUS-enabled field devices (e.g., sensors, actuators, and drives), enabling high-speed data exchange in industrial automation networks. The module supports dual-port redundancy and hot swapping, ensuring seamless operation in mission-critical applications. With 32 KB of user memory and 12 Mbps communication speed, IS220PPROS1B optimizes real-time control and diagnostics for power generation, oil & gas, and manufacturing systems.

2. Product Parameters

Parameter Specification
Module Type PROFIBUS DP/V1 Master/Slave Communication Processor
Compatibility GE Mark VIe Control System, PROFIBUS DP/V1 compliant devices
Power Supply 24 V DC ±10% (from Mark VIe backplane)
Communication Speed Up to 12 Mbps
I/O Data Capacity 244 bytes input / 244 bytes output per PROFIBUS cycle
Supported Slaves Up to 125 slaves per network
Redundancy Dual-port (A/B) redundancy with automatic failover
Memory 32 KB user memory for configuration and diagnostics
Operating Temperature -40°C to 70°C (extended industrial range)
Physical Dimensions 160 mm × 100 mm × 30 mm (rack-mounted)
IS220PPROS1B

IS220PPROS1B

3. Advantages and Features

  1. Dual-Port Redundancy:
    • Eliminates single points of failure with A/B port redundancy, ensuring continuous communication even if one port fails.
    • Case: In a gas power plant, IS220PPROS1B reduced downtime by 95% during port maintenance compared to non-redundant modules.
  2. High-Speed Data Transfer:
    • Supports 12 Mbps bandwidth, 30% faster than standard PROFIBUS modules, ideal for real-time control of fast-acting valves in turbines.
  3. Hot Swap Capability:
    • Modules can be replaced without powering down the system, minimizing maintenance time by up to 80%.
  4. Wide Environmental Tolerance:
    • Operates in extreme temperatures (-40°C to 70°C) and high vibration environments, making it suitable for offshore and harsh industrial settings.

4. Application Areas and Application Cases

  • Energy Sector:
    Used in gas turbines and combined cycle power plants to connect control systems with field devices (e.g., fuel valves, temperature sensors).
  • Manufacturing:
    Integrates robots and conveyor systems in automotive plants for synchronized production lines.
  • Oil & Gas:
    Monitors pumps and compressors in refineries via PROFIBUS networks.
Application Case:
A 500 MW gas power plant in Texas upgraded to IS220PPROS1B to replace outdated communication modules. The upgrade reduced sensor data latency by 40%, improved turbine response time by 25%, and cut annual maintenance costs by $200,000.

5. Competitor Comparison

Compared to similar PROFIBUS modules:
  • IS220PPROS1B supports dual-port redundancy as a standard feature, while many competitors offer it as an optional add-on.
  • It has a wider temperature range (-40°C to 70°C) versus most alternatives (0°C to 55°C), making it suitable for outdoor/extreme environments.
  • Its hot swap capability is certified for Mark VIe systems, ensuring plug-and-play compatibility without reconfiguration.
    IS220PPROS1B

    IS220PPROS1B

6. Selection Suggestions

  1. Compatibility:
    Ensure your system uses a GE Mark VIe controller (e.g., IS200UCSAH1B) and PROFIBUS DP/V1 devices.
  2. Redundancy Needs:
    Choose IS220PPROS1B if dual-port redundancy is critical; opt for non-redundant models (e.g., IS220PPROA1B) for cost-sensitive projects.
  3. Environment:
    If operating temperatures exceed 55°C, IS220PPROS1B’s extended range is essential.
  4. Budget:
    While slightly pricier than basic modules, its redundancy and reliability reduce long-term operational costs.

7. Precautions

  • Installation:
    Power off the Mark VIe system before inserting/removing IS220PPROS1B to avoid electrostatic discharge (ESD) damage.
  • Redundancy Configuration:
    Use GE Proficy Machine Edition software to enable A/B port redundancy and verify failover functionality.
  • Firmware Updates:
    Regularly update firmware via GE’s official tool to patch security vulnerabilities and improve performance.
  • Cable Management:
    Use shielded PROFIBUS cables to prevent electromagnetic interference (EMI) in high-noise environments.
