Description
1. Product Description
The WOODWARD 5501-380 is a high-performance Analog/Discrete Cable Assembly engineered for seamless integration with Woodward’s MicroNet control systems. This cable serves as a critical link between analog and discrete input/output modules and controllers, ensuring reliable signal transmission in demanding industrial environments. With its robust construction and advanced shielding, the 5501-380 supports applications such as turbine control, power generation, and process automation, where precision and durability are paramount.
The WOODWARD 5501-380 is a high-performance Analog/Discrete Cable Assembly engineered for seamless integration with Woodward’s MicroNet control systems. This cable serves as a critical link between analog and discrete input/output modules and controllers, ensuring reliable signal transmission in demanding industrial environments. With its robust construction and advanced shielding, the 5501-380 supports applications such as turbine control, power generation, and process automation, where precision and durability are paramount.
2. Product Parameters
| Parameter | Specification |
|---|---|
| Model Number | 5501-380 |
| Type | High-Density Analog/Discrete Cable |
| Length | 15 ft (4.57 m) or 20 ft (6.1 m) |
| Conductor Gauge | AWG 24 (0.5 mm²) |
| Connector Type | Deutsch DT06-17S |
| Cable Type | Shielded Twisted Pair (STP) |
| Operating Temperature | -40°C to +85°C |
| Certifications | UL, CE |
| Compatibility | MicroNet control systems |
WOODWARD 5501-380
3. Advantages and Features
- Enhanced Signal Integrity: Advanced shielding minimizes EMI/RFI interference, ensuring accurate data transmission.
- Compact Design: High-density layout optimizes space usage in complex control systems.
- Industrial-Grade Durability: Resistant to extreme temperatures, vibrations, and chemical exposure.
- Plug-and-Play Installation: Pre-terminated connectors reduce setup time and errors.
- UL-Certified Safety: Meets global safety standards for critical applications.
4. Application Areas and Case Studies
- Power Generation: Used in thermal power plants to connect sensors and actuators in boiler control systems.
- Oil and Gas: Integrates with MicroNet systems for real-time monitoring in refineries.
- Manufacturing: Supports automated machinery in automotive assembly lines.
- Case Study: A European energy company reduced troubleshooting time by 30% after adopting the 5501-380, achieving consistent signal reliability in high-vibration environments.
5. Competitor Comparison
Compared to standard cables, the 5501-380 offers superior EMI protection and a broader temperature range, making it ideal for harsh industrial settings. Its modular design also allows for easier expansion compared to rigid alternatives.
Compared to standard cables, the 5501-380 offers superior EMI protection and a broader temperature range, making it ideal for harsh industrial settings. Its modular design also allows for easier expansion compared to rigid alternatives.
WOODWARD 5501-380
6. Selection Recommendations
- Compatibility: Verify cable length and connector type align with your MicroNet system’s requirements.
- Environmental Factors: Choose the appropriate cable type (e.g., STP) based on electromagnetic interference risks.
- Cost Efficiency: Balance upfront investment with long-term savings from reduced downtime.
7. Precautions
- Installation: Power off the system before connecting cables to prevent electrical damage.
- Cable Routing: Avoid routing near high-voltage lines to minimize interference.
- Maintenance: Regularly inspect connectors for corrosion or loose connections.
