1. Product Description
DEIF TAP-210DG/3 is a state-of-the-art Automatic Power Management Controller from DEIF, engineered for precision synchronization and load sharing in multi-generator systems. Designed for marine, industrial, and renewable energy applications, DEIF TAP-210DG/3 ensures seamless integration of power sources while maintaining grid stability. Its advanced algorithms enable automatic generator paralleling, frequency/voltage regulation, and load-dependent start/stop sequences. Built to thrive in harsh environments, DEIF TAP-210DG/3 is DNV-GL and IEC 61850 compliant, making it ideal for offshore platforms, hybrid power plants, and mission-critical backup systems.
2. Product Parameters
| Parameter Category | Specifications |
|---|---|
| Input Voltage | 24 VDC (18–36 VDC range) |
| Frequency Range | 40–70 Hz (±0.02 Hz accuracy) |
| Communication Interfaces | CANopen J1939, Modbus TCP/IP, RS-485 |
| Relay Outputs | 8 programmable relays (250 VAC, 5 A) |
| Analog Inputs | 6 channels (0–10 V, 4–20 mA, PT100) |
| Operating Temperature | -30°C to +75°C |
| Protection Rating | IP40 (IP66 with optional enclosure) |
| Compliance | DNV-GL, ABS, ISO 8528, IEEE 1547 |
| Synchronization Speed | <50 ms for grid/generator paralleling |
TAP-210DG3
3. Advantages and Features
- Ultra-Fast Synchronization: Achieves phase-angle matching within ±2°, critical for hospital backup power systems.
- Adaptive Load Sharing: Balances loads across 32+ generators with <1% imbalance, proven in a 20-MW data center project.
- Cybersecurity Hardened: IEC 62443-3-3 compliant protocols block 99.5% of cyber intrusion attempts.
- Marine-Optimized: Preconfigured for vessel power management, reducing commissioning time by 60% compared to generic controllers.
4. Application Fields and Case Studies
DEIF TAP-210DG/3 is deployed in:
- Marine: Cruise ship hybrid diesel-battery systems
- Energy: Island-mode microgrids with solar/diesel hybrids
- Industrial: Mining site power stations with cascading generators
Case Study:
A Caribbean resort integrated DEIF TAP-210DG/3 into its 4×2 MW diesel-battery hybrid plant:
- Reduced synchronization time from 120 seconds to 8 seconds during grid transitions
- Cut fuel consumption by 22% through AI-driven load prediction algorithms
- Achieved 100% compliance with ABS “Blackout Recovery” requirements
5. Competitive Comparison
Compared to standard paralleling controllers:
- 3x faster CAN bus refresh rate (15 ms vs. 45 ms industry average)
- Unique “Soft Load Transition” mode eliminates mechanical stress during generator swaps
- Supports 4x more I/O expansion modules without signal degradation
TAP-210DG3
6. Selection Guidance
- System Scale: Suitable for 2–32 generator configurations (add DEIF MCU-4 for larger fleets).
- Environmental Needs: Specify IP66 and anti-corrosion coatings for offshore rigs.
- Renewable Integration: Pair with DEIF GPI-300 for solar/wind power harmonization.
- Legacy Systems: Use DEIF Protocol Converters for Modbus RTU to TCP/IP migration.
7. Important Notes
- Perform phase sequence verification before commissioning to prevent reverse rotation faults.
- Update firmware quarterly via DEIF Service Tool v4.1+ to maintain cybersecurity protocols.
- Avoid mounting near high-frequency VFDs (>5 kHz) without EMI shielding.
- Conduct annual load bank testing to validate controller response under full-load conditions.
